There are many auxiliaries in the gas boiler heating system, and the burner is the most important device. In the process of heat supply, the burner may be burned. The reasons for burning include the following:

   1. The burners of gas-fired boilers are burnt out due to many factors. For example, the furnace temperature of the gas-fired boiler is too high, exceeding the maximum allowable temperature limit, which enhances the radiation heat transfer of the high-temperature flue gas in the furnace to the burner and increases the wall temperature of the burner nozzle, resulting in damage.

   2. The burning out of the burner of the gas-fired boiler may also be related to the deflection of the flame base of the furnace, because the temperature of the furnace and the nozzle temperature of the burner are unevenly distributed, and the nozzle wind speed of the four corner burners on the same layer of the boiler is also unevenly distributed, so the flame base is skewed.

   3. When adjusting the gas-fired boiler, if the secondary wind speed is controlled too small, it will lead to too close ignition distance of gas, resulting in excessive heating deformation and damage of burner nozzle. In addition, when the high and low loads of the gas-fired boiler are changed, the adjustment is not timely, the upper secondary sealing nozzle cannot be cooled, and the burner will also be burned.

   In short, after the burner is damaged, it will have a great impact on the whole gas-fired boiler. Therefore, users should strengthen the control and adjustment of the boiler during normal use, including timely mastering the changes of gas pressure and quality, so as to ensure the reasonable ratio of gas and hot air; Observe the ignition of the gas and adjust the size of the secondary air valve in time... When the high and low load conditions are changed, adjust the negative pressure combustion in the furnace, adjust the ratio of gas and hot air, ensure that the furnace flame is not skewed, and coordinate the gas opening of each layer together.

   In addition, the material of burner in gas boiler can be properly improved. It is recommended to select excellent alloy steel material and add anti-wear and heat-resistant function. High temperature resistant stainless steel material is selected for the swirl blade, so as to avoid the deformation and damage of the burner nozzle caused by the burning and falling of the swirl blade. In addition, the standard of gas boiler burner must be adjusted in strict accordance with the drawings to ensure the tangential combustion of flame in the furnace and the stable operation of gas boiler.
